  3. Gecko 3.6kW Flow Thru Heater MSPA
Electrical

Gecko 3.6kW Flow Thru Heater MSPA

https://spaparts.glodo.cloud/web/image/product.template/744/image_1920?unique=a0df8bc

Not Available For Sale

  • Brand
  • Product Type
  • Power kW
  • Tube Diameter Reference
  • Tube Length
  • Assembled Length
  • Element Material

This combination does not exist.

Contact Us
  • VISA
  • Mastercard
  • Paypal
  • Google Pay
  • Apple Pay
Product Description
Box Quantity: 1 Power: Volts: 230 Hz: 50 KW: 3.6 Amps: 14.4 Specifications: Sensor compatibility: Gecko & Hydroquip probe and ribbon styleRequired flow rate: Set by pressure switchFlow detection: 2-PSI Tecmark pressure switch Compatible With: Gecko MSPA control box (the big blue one). Also replaces Canspa heater SN 3636603051350 Connections & Fixings: Usually held in the blue plastic moulding of the control box at the bottom of the Spa pack. Hi limit sensor pouch sits on top of the heater, also known to be used with the ribbon style hi-limit. 2" white plastic female sockets to connect to plumbing. You will need to re-connect your pressure switch also. Dimensions: Length: 381 mm Diameter: 50.8 mm Between terminals: 31.75 mm Overall length complete: 495.3 mm Additional Notes: If your heater looks the same as this one it most probably is but contact us if you need further help.
Product Attributes
Brand: Gecko
Product Type: Common Heater Tube
Power kW: 3.6kW
Tube Diameter Reference: 2 inch
Tube Length: 365mm
Assembled Length: 480mm
Element Material: Incoloy
Product Attributes
Brand: Gecko
Product Type: Common Heater Tube
Power kW: 3.6kW
Tube Diameter Reference: 2 inch
Tube Length: 365mm
Assembled Length: 480mm
Element Material: Incoloy
Product Description
Box Quantity: 1 Power: Volts: 230 Hz: 50 KW: 3.6 Amps: 14.4 Specifications: Sensor compatibility: Gecko & Hydroquip probe and ribbon styleRequired flow rate: Set by pressure switchFlow detection: 2-PSI Tecmark pressure switch Compatible With: Gecko MSPA control box (the big blue one). Also replaces Canspa heater SN 3636603051350 Connections & Fixings: Usually held in the blue plastic moulding of the control box at the bottom of the Spa pack. Hi limit sensor pouch sits on top of the heater, also known to be used with the ribbon style hi-limit. 2" white plastic female sockets to connect to plumbing. You will need to re-connect your pressure switch also. Dimensions: Length: 381 mm Diameter: 50.8 mm Between terminals: 31.75 mm Overall length complete: 495.3 mm Additional Notes: If your heater looks the same as this one it most probably is but contact us if you need further help.
